Neith Metals, located in Cairo, Egypt, stands out as a top manufacturer and supplier of high-quality stainless steel products, providing dependable solutions for a range of industrial and commercial needs. Among their standout products, the Stainless Steel 317L Hex Bars and Rods are celebrated for their exceptional corrosion resistance, impressive strength, and long-lasting durability. Crafted with precision and adhering strictly to international standards, these bars and rods are built to thrive in tough environments. By blending cutting-edge manufacturing technology with expert craftsmanship, Neith Metals guarantees consistent quality, performance, and reliability, making them a go-to choice for high-performance stainless steel materials.
The Stainless Steel 317L Hex Bars and Rods are an austenitic alloy that includes 17–19% chromium, 11–15% nickel, and 3–4% molybdenum, all while maintaining a low carbon content of less than 0.03% to boost corrosion resistance and weldability. On the mechanical side, they boast a tensile strength of about 515 MPa, a yield strength close to 205 MPa, and an elongation of up to 40%, ensuring they can handle stress with toughness. The addition of molybdenum enhances their resistance to pitting, crevice corrosion, and oxidation at elevated temperatures, making them perfect for demanding industrial and marine settings.
Dimensions : ASTM, ASME
Standard : ASTM / ASME SA A276, A479, ASTM A493
Length : Random, Fix & Cut Length
Size : 20MM to 150MM
| Element | C | Cr | Mn | Ni | P | S | Si |
| SS 317l | 0.03 max. | 18.0 – 20.0 | 2.00 max. | 11.0 – 14.0 | 0.045 max. | 0.03 max. | 1.00 max. |
| Element | Density | Melting Range,℃ | Tensile Strength | Yield Strength | Elongation | Hardness (Brinell) |
| SS 317l | 8 | 1450 ℃ | 515 | 205 | 40 | 217 |
| HEXAGONS | ||
|---|---|---|
| Size(mm) | WT PER FEET IN KGS | WT PER MTR IN KGS |
| 16 | 0.55 | 1.79 |
| 18 | 0.69 | 2.27 |
| 20 | 0.85 | 2.80 |
| 22 | 1.03 | 3.39 |
| 25 | 1.33 | 4.38 |
| 28 | 1.67 | 5.49 |
| 30 | 1.92 | 6.30 |
| 32 | 2.19 | 7.17 |
| 36 | 2.77 | 9.07 |
| 38 | 3.08 | 10.11 |
| 40 | 3.41 | 11.20 |
| 45 | 4.32 | 14.18 |
| 50 | 5.34 | 17.50 |
| 56 | – | – |
| 60 | – | – |
| 65 | – | – |
| 70 | – | – |
| 75 | – | – |
| 80 | – | – |
| 90 | – | – |
| 100 | – | – |
SS 317L Hex Bars/Rods are commonly used in chemical processing, marine environments, pharmaceuticals, and food processing due to their excellent corrosion resistance and high strength. They are ideal for handling aggressive chemicals, including sulfuric acid, bleaching solutions, and pulp liquor. In construction, they are used for structural components and fittings.
SS 317L Hex Bars/Rods typically range from 6 mm to 100 mm in diameter, with lengths up to 6 meters. Tolerances generally conform to ±0.5 mm for diameter. These dimensions and tolerances ensure precision for machining, making them ideal for applications requiring high strength, corrosion resistance, and tight fit.
The high chromium (18-20%) and molybdenum (3-4%) content in SS 317L enhances its resistance to pitting and crevice corrosion by forming a passive oxide layer that protects against chloride-induced degradation. The low carbon content further reduces the risk of stress corrosion cracking, ensuring durability in harsh chloride environments.
These Stainless Steel 317L Hex Bars and Rods find their place in industries that demand outstanding corrosion resistance, mechanical strength, and thermal stability. They’re frequently used in chemical and petrochemical processing, marine applications, pulp and paper manufacturing, and food processing equipment. Common applications include fasteners, shafts, valves, structural supports, and components that face harsh or corrosive conditions. Their low carbon content not only ensures excellent weldability but also resistance to sensitization. With their superior strength, durability, and corrosion resistance, the Stainless Steel 317L Hex Bars and Rods from Neith Metals provide reliable, long-lasting performance for challenging industrial, engineering, and commercial applications.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
