Neith Metals, based in Cairo, Egypt, has built a solid reputation as a reliable manufacturer and supplier of Stainless Steel Bright Bars and Rods, serving a diverse array of industrial and commercial sectors. With cutting-edge production facilities and rigorous quality control measures, Neith Metals ensures that its products meet international standards for precision, strength, and finish. Their bright bars and rods are celebrated for their exceptional surface quality, resistance to corrosion, and precise dimensions. Neith Metals caters to industries like construction, automotive, machinery, and engineering, establishing a strong reputation for reliability, durability, and customer-centric solutions in both regional and global markets.
The Stainless Steel Bright Bars and Rods from Neith Metals are primarily made up of iron, chromium (16–20%), nickel (8–12%), along with trace elements such as molybdenum, manganese, and carbon. This well-balanced composition grants them outstanding corrosion resistance, toughness, and a fine surface finish. In terms of mechanical properties, these bars and rods boast a tensile strength ranging from 500 to 800 MPa, yield strength between 200 and 450 MPa, and elongation of up to 40%, depending on the specific grade. Their excellent machinability, formability, and durability make them perfect for demanding applications that require precision and long-lasting performance.
Standards : ASTM A276, ASTM A484, AISI
Grade : 201, 202, 301, 302, 303, 304, 304H, 304L, 316, 316H, 316L, 309, 309S, 310, 310S, 316Ti, 317, 317L, 347, 321, 321H, 410, 416, 420, 430, 430F, 431, 440C, 630, 17-4PH, F51
Range : from2.00mm to 6.35mm (0.078″ to 0.25″)dia.
Tolerance : DIN 671, ASTM A484 & as per customer’s specific requirement.
Finish : Cold drawn, Centreless Ground, Polished
| Grade | Su | C | Si | P | Cr | Ni | M | Mo | Other |
|---|---|---|---|---|---|---|---|---|---|
| 316 | 0.030 max | 0.08 max | 0.75 max | 0.045 max | 16.0-18.0 | 10.0 14.0 | 2.00 max | 2.0 3.0 | – |
| 317L | 0.030 max | 0.035 max | 0.75 max | 0.045 max | 18.0-20.0 | 11.0 14.0 | 2.00 max | 3.0 4.0 | – |
| 304 | 0.030 max | 0.08 max | 0.75 max | 0.045 max | 18.0-20.0 | 8.0 11.0 | 2.00 max | – | – |
| 310 S | 0.030 max | 0.08 max | 1.5 max | 0.045 max | 24.0-26.0 | 19.0 22.0 | 2.00 max | 3.0 4.0 | – |
| 347 H | 0.030 max | 0.04 0.10 | 0.75 max | 0.045 max | 17.0- 19.0 | 9.0 13.0 | 2.00 max | – | 10C(Cb+Ta)<1.10% |
| 321 | 0.030 max | 0.08 | 0.75 max | 0.045 max | 17.0-20.0 | 9.0 12.0 | 2.00 max | – | 5C 0.70% |
| Grade | Tensile Strength | Yield Strength (0.2%Offset) | Density | Elongation | Melting Point |
|---|---|---|---|---|---|
| SS 303 | Psi – 85,000 | Psi – 45,000 | 55% | 50 % | Rb 180 |
| SS 202 | 515 MPa | 275 MPa | 8.0 g/cm3 | 40 % | 1454 °C |
| SS 304 | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 8.0 g/cm3 | 40% | 1400 °C |
| SS 304L | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 8.0 g/cm3 | 40% | 1400 °C |
| SS 316 | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 8.0 g/cm3 | 35 % | 1454 °C |
| SS 316L | 485 Min | 170 Min. | 8.0 g/cm3 | 40 % | 1400 °C |
|
Drawn Bar |
Min. (mm) |
Max. (mm) |
Drawn Bar |
Min. (inch) |
Max. (inch) |
|---|---|---|---|---|---|
|
Rounds |
14 mm |
76 mm |
Rounds |
5/8” |
3” |
|
Flats Width :
Height : |
20 mm
5mm |
100 mm
40 mm |
Flats Width :
Height : |
3/4″
1/2″ |
4”
1-1/2” |
|
Squares |
14 mm |
65 mm |
Squares |
1/2″ |
2-1/2” |
|
Hexagonals |
12 mm |
60 mm |
Hexagonals |
5/8” |
2” |
|
Bright Bar Weight Calculation Formula |
|
|
Bright Bar Weight Formula
0.00623 X ( mm ) Diam X ( mm ) Diam = Weight / Meter
0.0019 X ( mm ) Diam X ( mm ) Diam = Weight / Feet |
Square Bar Weight Formula0.00788 X ( mm ) Diam X ( mm ) Diam = Weight / Meter
0.00240 X ( mm ) Diam X ( mm ) Diam = Weight / Feet
|
|
Brightagonal Bar Weight Forumla
0.00680 X ( mm ) Diam X ( mm ) Diam = Weight / Meter
0.002072 X ( mm ) Width X ( mm ) Diam = Weight / Feet |
Bright Bar Weight Forumla
0.00798 X ( mm ) Thickness X ( mm ) Width = Weight / Meter
0.00243 X ( mm ) Width X ( mm ) Thickness = Weight / Feet |
Yes, stainless steel bright bars and rods can be customized in size according to specific requirements. They are available in various diameters, lengths, and finishes to suit diverse industrial applications.
Yes, stainless steel bright bars are highly corrosion-resistant due to their chromium content, which forms a protective oxide layer, preventing rust and ensuring durability in various harsh environments and applications.
Yes, stainless steel bright bars can be welded. They are compatible with various welding methods, including TIG, MIG, and stick welding. However, proper precautions, such as controlling heat input, are needed to maintain corrosion resistance and prevent distortion.
Neith Metals’ Stainless Steel Bright Bars and Rods find applications across various industries due to their strength, smooth finish, and corrosion resistance. They are commonly used in the production of fasteners, shafts, bolts, nuts, pins, and machine components. In the construction industry, they serve as frameworks, supports, and architectural elements. The automotive, marine, and food processing sectors also depend on these products for high-performance and hygienic applications. Their blend of mechanical strength, surface brilliance, and versatility makes them an ideal choice for both aesthetic and functional engineering needs.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
