Neith Metals, located in Cairo, Egypt, stands out as a top manufacturer and supplier of Stainless Steel Forged Bars and Rods, catering to a diverse array of industrial and engineering needs. By harnessing cutting-edge forging technology and high-quality raw materials, Neith Metals ensures that their products adhere to international standards for strength, precision, and durability. Their forged bars and rods are celebrated for their outstanding mechanical performance, resistance to corrosion, and precise dimensions. With a strong focus on innovation and quality, Neith Metals delivers dependable stainless steel solutions to industries throughout Egypt and beyond, fostering long-lasting customer satisfaction and trust.
The Stainless Steel Forged Bars and Rods from Neith Metals are primarily made up of iron, chromium (16–20%), nickel (8–12%), along with trace amounts of molybdenum, manganese, and carbon. This well-balanced composition boosts their corrosion resistance, toughness, and overall strength. In terms of mechanical properties, these products showcase a tensile strength ranging from 600 to 850 MPa, yield strength between 250 and 500 MPa, and an elongation of up to 35%, depending on the specific grade and forging process. Their remarkable toughness, fatigue resistance, and structural integrity make them perfect for heavy-duty applications that face high stress and challenging environments.
Standards : ASTM A276, ASTM A484, AISI
Grade : 201, 202, 301, 302, 303, 304, 304H, 304L, 316, 316H, 316L, 309, 309S, 310, 310S, 316Ti, 317, 317L, 347, 321, 321H, 410, 416, 420, 430, 430F, 431, 440C, 630, 17-4PH, F51
Range : from 2.00mm to 6.35mm (0.078″ to 0.25″)dia.
Tolerance : DIN 671, ASTM A484 & as per customer’s specific requirement.
Finish : Cold drawn, Centreless Ground, Polished
| Grade | Su | C | Si | P | Cr | Ni | M | Mo | Other |
|---|---|---|---|---|---|---|---|---|---|
| 316 | 0.030 max | 0.08 max | 0.75 max | 0.045 max | 16.0-18.0 | 10.0 14.0 | 2.00 max | 2.0 3.0 | – |
| 317L | 0.030 max | 0.035 max | 0.75 max | 0.045 max | 18.0-20.0 | 11.0 14.0 | 2.00 max | 3.0 4.0 | – |
| 304 | 0.030 max | 0.08 max | 0.75 max | 0.045 max | 18.0-20.0 | 8.0 11.0 | 2.00 max | – | – |
| 310 S | 0.030 max | 0.08 max | 1.5 max | 0.045 max | 24.0-26.0 | 19.0 22.0 | 2.00 max | 3.0 4.0 | – |
| 347 H | 0.030 max | 0.04 0.10 | 0.75 max | 0.045 max | 17.0- 19.0 | 9.0 13.0 | 2.00 max | – | 10C(Cb+Ta)<1.10% |
| 321 | 0.030 max | 0.08 | 0.75 max | 0.045 max | 17.0-20.0 | 9.0 12.0 | 2.00 max | – | 5C 0.70% |
| Grade | Tensile Strength | Yield Strength (0.2%Offset) | Density | Elongation | Melting Point |
|---|---|---|---|---|---|
| SS 303 | Psi – 85,000 | Psi – 45,000 | 55% | 50 % | Rb 180 |
| SS 202 | 515 MPa | 275 MPa | 8.0 g/cm3 | 40 % | 1454 °C |
| SS 304 | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 8.0 g/cm3 | 40% | 1400 °C |
| SS 304L | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 8.0 g/cm3 | 40% | 1400 °C |
| SS 316 | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 8.0 g/cm3 | 35 % | 1454 °C |
| SS 316L | 485 Min | 170 Min. | 8.0 g/cm3 | 40 % | 1400 °C |
| Type | Peeled nd Ground | Cold Drawn and Polish | Peeled and Polished | Cold Drawn and Ground |
|---|---|---|---|---|
| Sizes (mm) | 20.00 – 50.00 | 3.00 to 75.00 | 40.00 – 150.00 | 10.00 to 75.00 |
| Sizes (inch) | 3/4 – 2.00 | 1/8 to3.00 | 1.50 – 6.00 | 5/6 to 2.50 |
| Tolerance | h9 to h11 | h8 to h11 | h11, h11-DIN 1013 | h8 to h11 |
| CD | CF | CG | BD | ST | P&T |
|---|---|---|---|---|---|
| Cold drawn | Cold finished | Centreless ground | Bright drawn | Smooth turned | Peeled and turned |
| P | HRAP | HF | SRE | PR | RT |
| Polished | Hot rolled annealed and pickled | Hot finished | Slit rolled edge | Peeled and reeled | Rough turned/peeled |
The typical lifespan of stainless steel forged bars varies based on usage, environment, and maintenance but generally lasts 20 to 50 years, with proper care, especially in corrosion-resistant conditions.
Yes, stainless steel forged bars and rods can be customized in size, including diameter, length, and shape, to meet specific requirements for various applications in industries like manufacturing and construction.
Stainless steel forged bars are considered environmentally friendly due to their recyclability, durability, and resistance to corrosion. They have a long lifespan, reducing the need for frequent replacements and minimizing waste.
Neith Metals’ Stainless Steel Forged Bars and Rods find extensive use in industries that demand high mechanical strength and durability. They are particularly well-suited for crafting components like shafts, gears, crankshafts, fasteners, flanges, and robust machine parts. In fields such as oil and gas, power generation, automotive, and marine engineering, these forged products consistently perform well under extreme pressure and temperature conditions. Their exceptional corrosion resistance and toughness make them ideal for both structural and mechanical applications, where precision, strength, and a long service life are crucial for optimal performance and safety.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
