Neith Metals is a reputable manufacturer and supplier of top-notch Alloy Steel F9 Bars and Rods, proudly based in Cairo, Egypt. With a strong dedication to engineering excellence and dependable supply, Neith Metals caters to a variety of industrial sectors both locally and internationally. Their Alloy Steel F9 Bars and Rods are well-known for their impressive durability, strength, and ability to withstand high temperatures and pressure. By leveraging cutting-edge manufacturing technologies and rigorous quality control measures, Neith Metals guarantees that each product aligns with global standards. Supported by a skilled team and years of industry experience, the company has established itself as a go-to partner for businesses in search of reliable alloy steel solutions.
Alloy Steel F9 Bars and Rods mainly consist of chromium (8–10%) and molybdenum (0.90–1.10%), along with controlled amounts of carbon, manganese, phosphorus, sulfur, and silicon. This specific composition offers remarkable corrosion resistance and strength at elevated temperatures. The mechanical properties feature a tensile strength ranging from about 415 to 585 MPa, a yield strength of roughly 205 MPa, and a commendable elongation of 20%. These bars are known for their exceptional hardness and toughness, making them perfect for heavy-duty applications. The alloy’s metallurgical stability and resistance to creep under high pressure and thermal conditions make it an excellent choice for challenging engineering environments.
| Steel Round Bars type | F9 Round bars Die Steel Bar |
|---|---|
| Spring steel | 65Mn, 1566, 60Si2Mn, 9260, etc. |
| Standards | ASTM A689, JIS G4801, DIN 17221, GB/T 18254, ASTM A295, JIS G4805, etc. |
| Cold heading steel | ML25, ML35, etc. |
| Alloy structural steel | 40CrNiMo, SAE4330, 42CrMo, 15Cr2Ni2, 40CrNi2Mo, 35CrMoV,12Cr1MoV, ASTM4130, SCM420, 40CrV, etc. |
| Bearing steel | GCr15, SAE52100, GCr15SiMn, 100CrMnSi6-4, SJU2, etc. |
| Available Material Grade | 42CrMo4/SCM440/AISI 4140/DIN 1.7225, 4130 / 1.7218, 4140 / 1.7225, 4340 / 1.6582, 5140 / 1.7035, 8620 / 1.6523, EN19 / EN24H13 alloy steel round bar, 42 Crmo4 Alloy Steel Round Bar, AISI 4140 alloy steel round bar , 42CrMo4 alloy steel rods
|
| Military steel | 20Cr2Ni4A, 18Cr2Ni4WA, 23CrNiMo7-4-7, etc. |
| F9 Round bars Diameter | 5mm-500mm (Customized size is acceptable) |
| F9 Round bars Length | 1m-9m or according to the customer’s requirement. |
| F9 Round bars Range | Range – 3.17mm to 350mm dia |
| F9 Round bars Technique | Forged/Hot Rolled/Cold Drawn/Peeled |
| F9 Round bars Surface | bright round bar, pickled round bar, black round bar |
| F9 Round bars Type | Round bar, rod, square bar, flat bar, hexagon bar, angle bar, channel bar, threaded bar |
| Package Details | Standard seaworthy package(wooden boxes package, pvc package, or other package) |
| Other processing service | Hot dipped Galvanized, pre-galvanized, Color painting,coated, cutting, bending,punching |
| Test Certificate | Mill Test Certificate as per EN 10204 / 3.1B |
| Grade | C | Mn | Si | P | S | Cr | Mo |
| Alloy Steel F9 | 0.15 max | 0.3-0.6 | 0.5-1 | 0.03 | 0.03 | 8-10 | 0.9-1.1 |
| Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 380 | 585 | 20 % |
|
SHAPE |
POUNDS PER FOOT |
|---|---|
|
Round |
D2 x 2.67 |
|
Hexagon |
D2 x 2.945 |
|
Square |
D2 x 3.4 |
|
Flat |
Thickness (in.) x Width (in.) x 3.4 |
Alloy Steel F9 Bars and Rods are mainly used in high-temperature applications like steam turbines, aerospace components, and power plants due to their strength and heat resistance.
Alloy Steel F9 offers excellent creep strength, high tensile strength, and resistance to thermal fatigue, making it ideal for high-pressure environments.
Alloy Steel F9 Bars and Rods find extensive use in industries that demand high strength and thermal resistance, such as power generation, oil and gas, petrochemicals, and refineries. These bars play a crucial role in the fabrication of pressure vessels, boilers, heat exchangers, and turbine components, where durability in extreme temperatures and pressures is essential. In the aerospace and automotive industries, they are utilized in engine parts and structural components. Furthermore, Alloy Steel F9 Bars and Rods are also used in industrial piping systems and fittings due to their corrosion resistance and mechanical reliability, making them a versatile option for high-performance applications.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
