Neith Metals, located in Cairo, Egypt, has made a name for itself as a top-notch manufacturer and supplier of high-quality Super Duplex Steel Zeron 100 Bars and Rods. With a strong focus on excellence and precision, this company consistently delivers products that not only meet international standards but also excel in tough industrial settings. Renowned for their impressive strength, corrosion resistance, and durability, Neith Metals’ Super Duplex Steel Zeron 100 Bars and Rods are trusted by various sectors, including oil and gas, marine, chemical processing, and power generation. Thanks to their state-of-the-art manufacturing facilities and a team of skilled professionals, Neith Metals guarantees consistent quality and customer satisfaction across their entire product lineup.
The Super Duplex Steel Zeron 100 Bars and Rods are primarily made up of chromium (25%), nickel (7%), molybdenum (3.6%), copper (0.7%), tungsten (0.5%), and nitrogen (0.22%), resulting in a well-balanced microstructure of austenite and ferrite. These alloys boast remarkable mechanical strength, with a tensile strength of about 800 MPa and a yield strength of 550 MPa. They also showcase excellent impact toughness and high resistance to pitting, crevice, and stress corrosion cracking, along with outstanding performance in high-pressure and high-temperature conditions, making them perfect for harsh and corrosive environments.
| Specifications | ASTM A276, A479, ASTM A182 / ASME SA276, SA479, SA182 |
|---|---|
| Grade | Super Duplex Steel UNS S32760 F55 |
| Finish | Cold (bright) drawn, centreless ground, hot rolled, smooth turned, peeled, slit rolled edge, hot rolled annealed, Rough Turned, Bright, Polish, Grinding, Centreless Ground & Black |
| Technique | uns S32760 Cold Drawn, Hot Rolled, Forged Round Bar, Rod, Cold Rolled |
| Tolerance | H8, H9, H10, H11, H12, H13K9, K10, K11, K12 or as per clients’ requirements |
| Round bar size | Diameter: 3-~800mm |
| Hex Bar size | 2-100mm A/F |
| Width: 10 to 500mm | |
| Square bar size | 4 to 100mm |
| Flat bar size | Thickness: 2 -100mm |
| Billet Size | 1/2″ to 495mm Diameter |
| Channel Bar | 80 x 40mm to 150 x 75mm section; 5.0 to 6.0mm thickness |
| Angle bar size | 3mm*20mm*20mm~12mm*100mm*100mm |
| Hollow Bar | 32mm OD x 16mm ID to 250mm OD x 200mm ID) |
| Section | 3.0 to 12.0mm thickness |
| Form | Precision Ground Bar, Flat Bar, Square, Round, Half Round Bar, Rod, Rectangle, Hex (A/F), T-Bar, Channel Bar,Blocks, Round Rod, Threaded, Profiles, Billet, Ingot, I/H Bar, Forging, Rings, Hollow, Triangle etc. |
| Rectangles Size | 33 x 30mm to 295 x 1066mm |
| Surface | Cold Drawn, Bright, Sand Blasting Finished, Hot Rolled Pickled, Hairline, Polished |
| Processing | Bar cutting to 650mm |
| Certificates | EN 10204 / 3.1 |
| Condition | Hardened & tempered, annealed |
| Our uns S32750 Round bar conforms to NACE MR0175/ISO 15156 | |
| Grade | Cr | Ni | Mo | C | W | Cu | N | Mn | Si | P | S | Fe |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Zeron 100 | 24.0-26.0 | 6.0-8.0 | 3.0-4.0 | 0.030 Max | 0.5-1.0 | 0.50-1.0 | 0.2-0.3 | 1.00 Max | 1.0 Max | 0.03 Max | 0.01 Max | Balance |
| Grades | Alloy Zeron 100 Tensile Strength, ksi | .2% Yield Strength, ksi | % Elongation in 50mm | Hardness Max. |
|---|---|---|---|---|
| Zeron 100 | 109 | 80 | 25 | 28 HRC |
| STANDARD | WERKSTOFF NR. | UNS |
|---|---|---|
| Zeron 100 | 1.4501 | S32760 |
Yes, Super Duplex Steel Zeron 100 bars can be welded. However, proper welding procedures and pre-heat treatments are essential to avoid issues like cracking and maintain its high strength and corrosion resistance.
Super Duplex Steel Zeron 100 rods are highly resistant to galvanic corrosion due to their exceptional corrosion resistance properties. However, if exposed to more active metals in a corrosive environment, some risk of galvanic corrosion may still exist.
Super Duplex Steel Zeron 100 rods are available in a range of diameters, typically from 10 mm to 300 mm, and can be customized based on specific requirements. They are commonly offered in finishes like hot-rolled, cold-rolled, and bright polished.
Super Duplex Steel Zeron 100 Bars and Rods find extensive use in industries that demand superior corrosion resistance and strength. They’re commonly utilized in offshore oil and gas platforms, subsea equipment, desalination plants, and chemical processing sectors. Their exceptional resistance to seawater corrosion makes them a go-to choice for marine and shipbuilding applications. Additionally, these bars and rods are essential in heat exchangers, pressure vessels, pumps, and valves that operate in chloride-rich environments. In the pulp and paper industry, they offer excellent resistance to both acidic and alkaline chemicals, ensuring reliability, longevity, and cost-effectiveness in challenging engineering and industrial operations.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Neith Metals is a leading manufacturer, supplier, and exporter of high-quality bars, rods, and forgings, catering to various industries in Alexandria, Egypt
